HS-B Series
In-Line Flexo Printer Folder Gluer with Automatic Bundling Machine
Fully computerized corrugated carton box production line
The HS-B series is an automatic corrugated carton box production line with an inline flexo folder gluer. This carton boxes making equipment includes units for feeding, printing, slotting, die cutting, folding-gluing, and bundling. It is possible to make computerized adjustments of box height, length, and width. Its vacuum transfer system ensures efficient printing, cutting, and gluing in a single process. This series of flexo printer folder gluers is easy to reconfigure for different orders and is well-suited for both large and medium-sized carton factories.
Technical Parameters
| Model | ||||
| Max. design speed (pcs/min) | 300 | 280 | 250 | 220 |
| Working speed (pcs/min) (depending on cardboard size and printing) | 0-280 | 0-250 | 0-200 | 0-180 |
| Max. feeding size (mm) | 900×2000 | 900×2400 | 1200×2400 | 1200×2800 |
| Skip feeding size (mm) | 850×1950 | 850×2350 | 1150×2350 | 1150×2750 |
| Max. printing size (mm) | 300×765 | 300×765 | 360×785 | 360×785 |
| Min. feeding size (mm) | 240×120 | 240×120 | 250×120 | 250×120 |
| Min. fold size (mm) | 7.2 | 7.2 | 7.2 | 7.2 |
| Standard printing plate thickness (mm) | 850×1950 | 850 ×2250 | 1150×2350 | 1150×2750 |
(Size can be customized according to customer requirements)
Main Configurations
- Computerized feeder unit
- 1. Lead edge feeder with adjustable air pressure for cardboard feeding
- 2. Dust suction brush with fan for efficient dust removal
- 3. Pneumatic side squaring system
- 4. Motorized adjustment for both side and back cardboard hold plates
- Computerized printing unit
- 1. Touch screen control for adjusting the phase movement of the printing roller
- 2. Plate hanging device for easy placement of printing plates
- 3. Printing roller equipped with a zero line for convenient print memory storage
- 4. Automatic ink circulation system with a low ink alarm device
- Computerized slotter unit
- 1. Touch screen control for adjusting box height
- 2. Touch screen control for adjusting box length and width
- 3. Storage of box size settings for easy recall
- Computerized die cutter unit
- 1. Pneumatic self-locking device for the die-cutting roll
- 2. Speed difference compensation mechanism
- 3. Equipped with a rubber grinding roller
- 4. Die cutter rubber pads from Taiwan or Italy
- Servo control folder gluer unit
- 1. Bottom folder gluer machine
- 2. Vacuum transfer for cardboard feeding
- 3. Large gluing wheel with motorized control for position adjustment
- 4. Servo motor controlled for precise folder gluer operation
- 5. Touch screen for computerized box size adjustment
- Auto bundling unit
- 1. Equipped with PP (Polypropylene) belt for more efficient bundling
- 2. Automatic squaring of cartons
- 3. Option for single or double lane bundling
